When you combine the powerful Sea Dragon 3000SF Pro Dual Beam with the Micro 3.0 camera, you’ve created the perfect duo. The bright yet also warm and color friendly Sea Dragon has a wide and even beam angle that covers the shooting angle of the Micro 3.0 camera well. The set includes a Flex-Connect single tray and grip, and allows for easy expansion into more lighting options.

The compact Sea Dragon 3000SF Pro Dual Beam Photo-Video light is the perfect all-around photo, video, and dive light. With a simple one-button push, you can switch from the wide 120° beam to a narrow 1500 lumen 15° spot beam. For imaging, the spot beam offers many creative opportunities such as to create a narrowly focused snoot or stage spotlight effect. The spot beam also serves as a primary or secondary dive light for most diving applications.

SPECIFICATIONS

Image Sensor:    16 mega pixel SONY IMX083 1/2.3” CMOS sensor
Image Resolution/Sizes:    16mp (4608×3456   4:3), 14mp (4608×3072  3:2), 12mp (4608×2592 16:9), 9mp (3456×2592  4:3), 7mp (3456×1944  16:9), 4mp (2304×1728  4:3), 3mp (2304×1296  16:9), 2mp (1920×1080  16:9)
Picture File Format:    JPEG (.jpg) and RAW (.dng)
Video Resolution/Sizes:    4K at 30fps (frames per second), 1080p at 120 fps, 1080p at 60 fps, 1080p at 30 fps, 720p at 120fps, 720p at 60fps, 720p at 30fps, 480p at 120fps, 480p at 60fps, 480p at 30fps
Video File Format:   MPEG4 h.264 (.mp4)
Audio Microphone:   Yes (mono)
Speaker:   Yes (mono)
Audio Format:   ACC (video/ audio compressed together)
Lens Aperture:   F2.8
Lens Optics:   7 element, fully multi-coated, aspheric optical lens
Focal Length:   3.37mm (35mm film equivalent = 19mm)
Focus Type:   Fixed-focus lens
Focus Range:   15” to Infinity (38cm to infinity)
Field of View:    100° diagonal shooting angle
Shutter Speed:   1/25 to 1/2000 second
Scene Modes:   Land Auto, Land Sports/Action, Dive, Snorkel and Ext Light mode (when using photo video light accessory)
Capture Modes:   Single, Continuous (shoots 10 16MP pictures in the 1st second and 2 pictures thereafter), Time Lapse (Saves as .mp4 file or as series of individual still images depending on setting), Burst (shoots ten 16MP JPEG or three JPEG+RAW pictures in 1 second) and AEB (Auto Exposure Bracketing)
White Balance Modes:   Auto, Manual, Underwater Deep, Underwater Shallow, Underwater Green, Daylight, Cloudy
ISO:  Auto, 100, 200, 400, 800, 1600, 3200
Exposure Value:  (EV) EV adjustable from -2.0 to +2.0 in 0.3 increments
Quality:   Super Fine, Fine and Standard
Sharpness: Standard, Hard and Soft
Metering: Center, Average and Spot
Color:  Standard, Vivid, Black/White, Sepia and Negative
Self Timer: 10 sec, 3 sec and 10+3 sec
LCD: 2.4” 260K TFT LCD color display
Status: LED Blinking red = charging, Solid red = fully charged
Solid green = Data connection made
Blinking green = Data connection not successful (Display will read: Clean USB pins & adapter. Use only original USB cable.)
Memory: (internal) 64GB internal memory
USB Format:   2.0
USB Cable Type:   USB-A to Micro-B, 2ft (60cm)
PC Connection PC:  Windows XP / 7 and up, MAC: OS 10.8 and up
Language Support On-Screen Display:   English, German, French, Spanish, Italian, Dutch, Turkish, Russian, simplified Chinese, traditional Chinese. Printed manual;  English. Online manual; German, French, Spanish, Italian, Dutch
Battery:   2000 mAh, 3.7v, 7.4Wh Internal Li-ion battery
Battery Life:   3+ hours when shooting pictures or recording 1080p-30fps video
2+ hours when RAW+JPEG images or recording 4K-30fps video
External Power:   Camera may be connected to 5v external power supply for full functionality
Note: External Power is only available on land above water
Charging:   Use any 5V USB wall charger (not included)
Includes USB cable (Type A to Micro-b) and 5-pin USB adapter
4 hour charging time with 1.5A+ wall charger
Phone App: SeaLife Micro 3+ app available for Android at Google Play store and iOS phone/tablet at Apple App Store, app supports phone/tablets running current or previous version operating system
WiFi:   Wi-Fi 802.11b/g/n (Approximate range = 100ft / 30m)
System Settings:   WiFi on/off, System Reset, Format, Date/Time, Memory Available, Mic off/low/med/high, Sound off/low/high, Quick View on/off, Language, System NTSC/PAL, Light Frequency 50Hz/60Hz, Date Stamp on/off, Auto Off/3min/5min, Upside-down shooting, Shortcut, SSID and FW version
Waterproof:   Individually depth tested to 200’ (60 m)
Altitude:   Operational to 25,000ft (7600m) above sea level
Shockproof:   3ft / 1m drop test
Buoyancy:   Negative; -50 grams underwater
Operating Temperature Land: 23°F to 122°F (-5°C to 50°C); Underwater: +33°F to +110°F (0.5 °C to 44°C)
Storage Temperature:   -20°F to +140°F (-29°C to +60°C)
Tripod/Tray Mount:   Standard ¼-20 UNC tripod threads
Certification:   CE, ROHS, FCC, IC
Weight:   11.6 oz. (329g)
Dimensions:   2.1” x 2.9” x 4.2” (5.4cm x 7.4cm x 10.7cm)
Packaged Weight:  2lbs (0.9kg)
Packaged Dimensions:   3.7” x 5.1” x 5.5” (9.5cm x 13.0cm x 14.0cm)
Warranty Period:   1 year limited warranty for manufacturing defects


Sea Dragon Pro Dual Beam Specifications

Body Material Anodized aluminum light head with fiber-reinforced polycarbonate body
Light Source/Bulb Type 1x wide beam COB LED (BridgeLux V18 COB LED Array COB)
1x narrow beam LED (Luminus SST-40-W LED)
2x red beam LED (Luminus SST-10-R LED)
Brightness White light: 3000 lumens (maintained throughout run time at full power)
Red light:  180 lumens
Brightness Control/Light Modes 100% wide ? 50% wide ? 25% wide ? 100% spot ? 50% spot ? Red [repeat]
Color Temperature 5000K for COB wide beam LED
6000K for narrow beam LED
Color Rendering Index* 90 for COB wide beam LED
70 for narrow beam LED
Beam Angle White Light: 120° on land / 90° underwater; Red light: 88° on land / 66° underwater
Battery Lithium Ion 7.4V, 3400 mAh, 25Wh (included)
Battery Charge Time 170 minutes
Run Time Wide Beam: 60 min at full power, 120 min at 50% power, 240 min at 25% power
Narrow Beam: 80 min at full power, 160 min at 50% power
Red beam: 240 min
Depth Tested to 330 feet/100 meters
Dimensions 8.5? x 9.5? x 2.3? (22cm x 24cm x 6cm), fully assembled with light head, battery, grip and tray
5.1? x 2.2? x 4.1? (13cm x 5.6cm x 10.4cm), head only
Weight 15.8 ounces (449 grams) light head w/battery installed
Bulb Life 35,000 hours
O-ring Dual silicone O-rings (lube included)
Buoyancy Negative; -111 grams underwater

Notes:

Avoid using this Sea Dragon light above water for prolonged periods of time. The light is designed for underwater use and water is needed to displace heat. The metal light head at full power will reach temperature of about 140F (60C) degrees within a few minutes, which may cause burning if touched. A thermal sensor will automatically dim the light if internal temperatures reaches 150F (65C) degrees. Immediately turn off light if any parts of the light become hot to the touch.
